GasBank Duo 5kg LPG Light Composite Refillable Bottle with Separate Inlet/Outlet

(No reviews yet) Write a Review
SKU:
400240
Availability:
1-2 working day delivery available
Weight:
4.70 KGS
Shipping:
£9.99 (Fixed Shipping Cost)
  • GasBank-Duo-5kg-LPG-Light-Composite-Bottle
  • GasBank Duo 5kg LPG Light Composite Bottle
  • GasBank Duo 5kg LPG Light Composite Refillable Bottle with Separate Inlet/Outlet
  • GasBank Duo 5kg LPG Light Composite Refillable Bottle with Separate Inlet/Outlet
  • GasBank Duo 5kg LPG Light Composite Refillable Bottle with Separate Inlet/Outlet
  • GasBank Duo 5kg LPG Light Composite Refillable Bottle with Separate Inlet/Outlet
  • GasBank Duo 5kg LPG Light Composite Refillable Bottle with Separate Inlet/Outlet
  • GasBank Duo 5kg LPG Light Composite Refillable Bottle with Separate Inlet/Outlet
MSRP: £229.99
£169.99 Inc. VAT
MSRP: £191.66
£141.66
Ex. VAT
— You save £60.00

0% interest for 4 months with PayPal Credit. Find out more

  • UK Bayonet Filling Point to JIC - Angled with Box
  • UK Bayonet Filling Point to JIC - Angled with White Box
  • UK Bayonet to JIC 3/4" Plate Filling Point Angled
  • UK Bayonet Filling Point to JIC - Angled with Cap and Bracket
  • UK Bayonet Filling Point to JIC - Straight with Box
  • UK Bayonet Filling Point to JIC - Straight with White Box
  • UK Bayonet to JIC 3/4" UNF Plate Filling Point Straight
  • UK Bayonet Filling Point to JIC - Straight with Cap and Bracket
  • GasBank DUO Direct Filling Set
  • Motorhome Gas Filter Unit with UK Adapter
  • 3/4" JIC Polypipe Cut-to-length Filler Line 3 meters Kit
  • 3/4" JIC Polypipe Cut-to-length Filler Line 3 meters Kit with Filter
  • 2m Copper Filler Pipe with Fittings
  • JIC LPG hose 1meter straight to straight ending autogas
  • JIC LPG hose 1.5meter straight to straight ending autogas
  • JIC LPG hose 2.25meters straight to straight ending autogas
  • JIC LPG hose 1 meter 90 degrees square to straight ending autogas
  • JIC LPG hose 1.5meter 90 degrees square to straight ending autogas
  • JIC LPG hose 2 meters 90 degrees square to straight ending autogas
  • Motorhome Regulator 30 mbar with IGT High Pressure EFV Pigtail
  • GOK Gas Regulator Crash Protection with IGT high pressure EFV gas hose
  • Truma Mono CS with pigtail IGT
  • Truma Gas Filter M20 x 1.5
  • Gas Manifold Distribution Tap 1 Way
  • Gas Manifold Distribution Block 2 way
  • Gas Manifold Distribution Block 3 way
  • Inline Gas Valve 8mm Compression Low Pressure
  • Gas Manifold Distribution Block 2 Ways
  • Gas Manifold Distribution Block 3 Ways
  • Gas Manifold Distribution Block 4 Ways
  • Travel set of three adapters for Bayonet LPG filling point covering all Europe
  • 6m x 8mm Copper Pipe with Fittings Kit
  • Cylinder Gas Bottle Retaining Strap Kit
  • 5kg GasBank Cylinder Gas Safety Locker
  • GasView LPG Cylinder Scale with Display and Smartphone App
  • TriGasAlarm - Gas detector for motorhomes
  • Teflon PTFE Tape White 0.1mm 13m
  • White gas drop out vent
  • 1/2" BSPP Female to 8mm Copper Pipe Compression Fitting
  • 3/8" BSPP Female to 8mm Copper Pipe Compression Fitting
  • 1/4" BSPP Female to 8mm Copper Pipe Compression Fitting
  • 1/2" BSPP Male to 8mm Copper Pipe Compression Fitting
  • 3/8" BSPP Male to 8mm Copper Pipe Compression Fitting
  • 1/4" BSPP Male to 8mm Copper Pipe Compression Fitting
  • LPG Brass Coupling Straight Ø8/Ø8mm
  • Copper Pipe Coupling 10mm to 8mm Pipe

Description

GasBank Duo 5kg light composite gas bottle

The final price depends on the selected options below.
The base price is for a cylinder only with fully fitted valves on top. It does not come with any filler, frame, or other accessories unless options are selected.

Install once and enjoy your journey

GasBank is an ultralight composite LPG gas cylinder with 80% overfilling protection valve (OPD). Gas cylinders that can be refilled at LPG stations. Perfect for camping, cooking, BBQ, heating at home, caravan, motorhome, boat, industrial burners and/or any application where a standard LPG cylinder can be used. Great feature of our bottle is separate inlet and outlet. You can easily and safely refuel the cylinder basically without any interference, with no disconnecting/connecting.

Made of a super lightweight composite material cylinder is light, very durable and meets high safety requirements.

Safe LPG filling throughout Europe

The cylinder is equipped with a certified gas multivalve with separate inlet and outlet which makes bottle real easy to refill.

Safety features

The GasBank valve, unlike the valves in standard LPG cylinders, has a unique OPD system that allows for safe filling at any LPG station. The automatic OPD (Overfill Protection) valve automatically stops filling when the gas level reaches 80%.

How to fill the DUO bottle?

DUO cylinders can be refilled by the remote refueling valve or adapters screwed directly onto the cylinder.

How does the DUO cylinder work?

DUO cylinders have separate inlets and outlets, so they can be refilled without disconnecting from the installation and can be connected to each other to increase the total capacity.

Do I have to disconnect the output in GasBank DUO while refilling gas?

It is not necessary to disconnect the DUO cylinder from the system during filling, it is recommended to close the outlet valve (blue), but it is not necessary.

External filling point

In most European countries refilling bottles is strictly forbidden even if equipped with 80% cut off valve. Sometimes pump has to be activated by worker before refilling.

Our bottles can be refilled remotely from filling point mounted on the panel or on the chassis, which is the only accepted way of refilling cylinders.

Gas regulator

The outlet pressure depends on gas level and gas temperature. Regulator should be used to maintain equal pressure.

Choose between Truma, Cavagna or GOK regulators.

Eurotunnel restrictions

Complete legal information is available here: https://www.eurotunnel.com/uk/traveller-info/vehicles/fuel-types/

Composite cylinders are allowed in Eurotunnel:

If travelling with a campervan, caravan or any other vehicle fitted with cooking facilities, any flammable gas container must be declared when asked and will be checked at the appropriate checkpoint by Eurotunnel Le Shuttle

Flammable gas containers may be transported with the following restrictions:

  • For portable containers (cylinders/bottles, etc): Maximum of 47kg per cylinder and no more than 50kg per Vehicle if more than 1 container;
  • For fixed containers (tanks): Maximum of 47kg per container and no more than 50kg per Vehicle if more than 1 container.
  • Fixed containers must be no more than 80% full. The capacity of the container will be checked by Eurotunnel staff.



Bottle specification

 5kg Cylinder
Height (mm) 400
Diameter (mm) 310
Empty Weight (kg) 3.60
LPG Capacity (approx litres) 9.5
Propane Capacity (kg) 5
Water Content (L) 12.5
