HANA
HANA H2002 GOLD 3CYL Injectors Rail
- SKU:
- 120231
- UPC:
- 49.79
- Weight:
- 0.40 KGS
- Shipping:
- Calculated at Checkout
Description
HANA TYPE H2002 GOLD 3Cylinders Injectors Rail (OEM) - Side Feed, Valtek connector, Exchangable nozzles
SALE -20%
BRAND NEW HANA H2002 OEM Injectors Rails are smaller, lighter and more convenient for installation thanks to compact construction and side feed.
The rail itself is made in proven vell known technology which provides low noise operration and very precise injection timings.
Rails can be dismantled for easy replacement of coils and injector pins.
HANA Injectors are best on the market considering value for money.
HANA GOLD Injectors are suitable for following engine power range:
- 6 Cylinders: 90~300HP
- 12 Cylinders: 180~600HP
Choose a proper nozzle size or leave us an info regarding HP and number of cylinders.
Technical details:
- Connector: VALTEK Type (Superseal AMP-Delphi)
- Coil resistance: 1.9Ω
- Voltage: 12V
- Max pressure: 4 bar
- Max Flow rate: 115 L/min
- Open Time: 2.36ms
- Closing time: 1.2ms
- Pick current: 4A
- Hold current: 2A
- Dimension: 140mm x 80mm x 40mm
- Weight: 0.25kg
HANA Injectors comparision chart:
NEW HANA | Former HANA | Nozzle | Maximum Power (HP) | Mesured with | ||||
HP/Cylinder (±15%) | 4 Clinders | 6 Cylinders | 8 Cylinders | |||||
Type A+ (BLUE) | Type A+ (BLUE) | - | 1.3 Ohm | 40 / 50 / 60 HP | 160 ~ 240 HP | 240 ~ 360 HP | 320 ~ 480 HP | Pressure 0.8/1.0/1.2 bar (with max.load) |
Type A (GOLD) | Type A (GREEN) | - | 1.9 Ohm | 33 / 42 / 50 HP | 132 ~ 200 HP | 198 ~ 300 HP | 264 ~ 400 HP | |
Type B (RED) | 2.4mm One stripe | | 1.9 Ohm | 26 / 32 / 39 HP | 104 ~ 156 HP | 156 ~ 234 HP | 208 ~ 312 HP | ||
Type C (BLACK) | 2.1mm Two stripes || | 1.9 Ohm | 20 / 25 / 30 HP | 80 ~ 120 HP | 120 ~ 180 HP | 160 ~ 240 HP | ||
Type D (VIOLET) | 1.9mm Three stripes ||| | 1.9 Ohm | 15 / 19 / 24 HP | 60 ~ 96 HP | 90 ~ 144 HP | 120 ~ 192 HP |
