Bullfinch
Bullfinch External Quick Release Gas Point for BBQ 8mm Orange Hose
- SKU:
- 400462
- Weight:
- 0.40 KGS
- Shipping:
- Calculated at Checkout
Description
Bullfinch External Quick Release Gas Point for BBQ 8mm Orange Hose
BBQ quick release external gas point for motorhomes and caravans.
Suitable for high pressure non-regulated gas and low pressure gas after regulator.
Made of thick high quality plastic.
The back connector with compression fitting takes 8mm copper, quick adapter is compatible with 8mm orange hose.
It requires to drill 60mm hole.
Technical Details
- Working pressure – 7 bar (max)
- Conforms to BS EN 331 and BS EN 1949 and made under a certified ISO9001 system
- Corrosion-resistant materials, LPG compatible
- Plastic parts made of high quality materials with long-term UV resistance
- Total sealing between device and wall of prefabricated structure
- Total sealing between cap and connection device
- Double gasket for optimal long-term safety
- Dimensions – 105 x 110 x 85 (deep) mm
- Body - Hot forged brass alloy CW617
- Ball valve + flare - Chrome/nickel plated brass alloy CW614
- Additional brass parts - Brass alloy CW614
- Plastic unit and cap - Polycarbonate reinforced with glass fibre
- Lever handle - ABS (Acrylonitrile Butadiene Styrene) – UV stable
- Hinges, springs and screws - stainless steel
- Rubber gaskets - NBR conforming to EN549 standard
- Wall gaskets and cap gaskets – UV, ozone resistant EPDM
- Ball valve seals: - PTFE
