Barracuda
Barracuda 1CYL Single Mount Injector
- SKU:
- 120600
- Weight:
- 0.15 KGS
- Shipping:
- Calculated at Checkout
Description
Barracuda BA1500 Series 1 Cylinder Single Mount Injector
Max flow: 120Nl/min with pressure 1,2bar
Coil resistance: 1,9Ω
Opening time: 1,9ms
Closing time: 1,2ms
Max intake pressure: 4,5bar
Work temperature: 20°C ÷ +120°C
Liveliness: more than 500 mln cycles
Selection of injector nozzles according to
engine power per single cylinder (estimated values):
| Ø [mm] | 1[bar] | 1.2[bar] | 1.5[bar] |
| 1.5 | 10-20HP | ||
| 1.6 | |||
| 1.7 | 10-20HP | ||
| 1.8 | 10-20HP | ||
| 1.9 | |||
| 2.0 | 20-30HP | ||
| 2.1 | |||
| 2.2 | 20-30HP | ||
| 2.3 | 20-30HP | ||
| 2.4 | 30-40HP | ||
| 2.5 | |||
| 2.6 | 30-40HP | ||
| 2.7 | 30-40HP | 40-45HP | |
| 2.8 | |||
| 2.9 | 40-45HP | 45-50HP | |
| 3.0 |
